 Rapier LOOMS -  MODEL GA758 Image
Rapier LOOMS - MODEL -AJL900

Specification


MODEL -AJL900 ( HIGH SPEED AIR JET - TOWEL LOOM )

The key to innovation -

    • YOUCHENG newest structure of high speed reed motion pilling mechanism.
    • Conjugate cam driven for beating up system to ensure the high speed insertion time with small shedding.
    •  6 and 4 linkages combination of beating up system to ensure high speed filling insertion time.
    • The optimal beating up for pilling balance mechanism.
    • Bold size beating shaft to ensure the beating up force during high speed.
    • Extra width loom with multistage beating up technology.

    Specification parameter -

      • Width of loom:  200cm, 230cm, 260cm, 280cm, 300cm, 320cm,340cm,360cm,380cm and 450cm
      •  Speed of loom:  380rpm to 700 rpm
      • Piling mechanism: The newest digit control high speed reed motion for piling mechanism.
      •  Filling insertion mechanism: 2-4 spray nozzles/valves to save energy air jet filling insertion
      • Picking finding mechanism: original mechanism without disengaging device for picking finding with maintenance free. (patent: 2014 10375947.0)
      • Battening up mechanism: Conjugate cam drive with oversize diameter shaft ( 100 mm) for battening up.
      • Weft selection mechanism: 4-6color weft selector.
      • Warp beam: Terry warp beam 1200mm, ground warp beam: 800mm
      • Control system: YOUCHENG NEW 2015 VERSION with full digit air jet control system, the whole working angle datum to be set directly, touch screen interface, digit control for taking up, let-off and let off terry yarn tension, digit control 10 P119 terry, auto-picking finding, stopping at picks fixed, auto-pulling lace, the droppers for terry warp and ground warp to display separately, saving energy system, to calculate the statistics of shift output with production efficiency for 30 days.
      • Processing edit: with computer for editing, datum modification at touch screen, transferring document with U disk.
      • Signal Synchronization: to make communication and automatic circulation with jacquard synchronously ( more easier and simpler for editing and co-ordinate with jacquard)
      • Wallboard: 16 cm thickness of wallboard for enforcing the stability.
