Specification

XH Series Electronic Jacquard

Fabric suitability: suitable for most jacquard-weaving applications such as trademarks, ties, terry cloths, Scarfs, decorative fabrics, curtain cloth, sofa cloth, bedclothes and clothing fabrics, etc.
Field of application: can be matched with kinds of Chinese or foreign rapier, water-jet, airjet and towel weaving machines.
Features: This series of jacquard adopts four eccentric wheels to realize steady transmission, which permits its less noise and longer lifetime. It realizes mechatronical weaving by inputting weaving CAD design patterns to control system via USB interface, which is characterized with quick pattern-shifting, high pattern-controlling precision, easy management and flexible application.

Main Technical Parameters:

Item	Electronic Jacquard
Model	1344~18000 hooks
Rotate Speed	200-650 / 200-650 rpm
Shedding Form	Double Lift, Clean bottom-open shed
Shed Height	Front shed 55-90mm, back shed 90-120mm,adjustable
Driving Mode	Chain/vertical-shaft

Product Overall Size:

Model	(mm) Length	(mm) Width	(mm) Height	Actual hooks
XH1344	1910	1020	1120	1536
XH2688	2350	1020	1120	2688
XH5376	2680	1230	1140	5184
XH6000	2880	1230	1140	6144
XH8000	3420	1230	1140	8256
XH12000	5790	1230	1410	12288
XH16000	6870	1230	1410	16512
XH18000	7258	1230	1410	18432
